On And Lux Off High Bay Motion Sensor IP20 Remote Control HNS211HB 240VAC

  • On And Lux Off High Bay Motion Sensor IP20 Remote Control HNS211HB 240VAC
  • On And Lux Off High Bay Motion Sensor IP20 Remote Control HNS211HB 240VAC
  • On And Lux Off High Bay Motion Sensor IP20 Remote Control HNS211HB 240VAC
  • On And Lux Off High Bay Motion Sensor IP20 Remote Control HNS211HB 240VAC
  • On And Lux Off High Bay Motion Sensor IP20 Remote Control HNS211HB 240VAC
Place of Origin Shenzhen, China
Brand Name Hynall
Certification RED, FCC, RoHS, ETL
Model Number HNS211HB
Minimum Order Quantity 300pcs
Price To be negotiated
Packaging Details Bubble bag + carton. (color box or blister package also available on request)
Delivery Time 3~4 weeks for bulk orders
Payment Terms T/T
Supply Ability 30,000pcs / month
Product Details
Input Voltage 220~240VAC 50Hz Rated Load Max. 400W(capacitive)
Stand-by Power ＜0.5W Control Type On/off , Lux Off
Model Name HNS211HB Mounting Height Max. 12m
Operation Temperature -20℃ ~ +70℃ Settting Remote Control
High Light

Lux Off High Bay Motion Sensor

,

IP20 High Bay Motion Sensor

,

240VAC Remote Control Motion Sensor
Leave a Message
Product Description

Model name: HNS211HB      AC input 220-240V AC on/off high bay motion sensor



This model is a AC input on and off function high bay motion sensor, easy installation and remote control setting will smply operated by end users.



Advantage:



1. Microwave motion sensor and daylight sensor 2 in 1

2. Max. 12m mounting height and 18m in diameter for detection range

3. Remote control setting

4. Dual-processor daylight sensor technology to achieve real built-in

5. Customized service: Yes







Product Information:



IP20       RoHS compliant          CE



Parameters:



5.8GHz frequency module simple on/off function and lux off  max. 12m high bay motion sensor
Input voltage: 220~240V
Rated load: Max. 400W (capacitive)
Technology: dual-processor daylight sensor  Zero-cross point operation



On And Lux Off High Bay Motion Sensor IP20 Remote Control HNS211HB 240VAC 0

On And Lux Off High Bay Motion Sensor IP20 Remote Control HNS211HB 240VAC 1

On And Lux Off High Bay Motion Sensor IP20 Remote Control HNS211HB 240VAC 2

On And Lux Off High Bay Motion Sensor IP20 Remote Control HNS211HB 240VAC 3

Press red “ ON/OFF” button, the fixture goes to permanent
on or permanent off mode, sensor is disabled.



Quit this mode: Press“ Auto”,“ Reset” or“ Ambient learn”

Sensor mode


Press Green “ Auto” button, it starts to work and all settings remain the same as the latest status before the light was switched on/off.

Reset function


Press orange “ Reset” button, all settings go back to the factory default setting:



Hold time= 1min
Sensitity= 100%
Daylight sensor= disable

Ambient learn



Press this button, the latest surrounding lux
value overwrites previous lux value learned, and set as the daylight threshold. This feature enables the fixture to function well in any real application circumstance.



On And Lux Off High Bay Motion Sensor IP20 Remote Control HNS211HB 240VAC 4On And Lux Off High Bay Motion Sensor IP20 Remote Control HNS211HB 240VAC 5
