| MOQ: | 1000 |
| Price: | To be negotiated |
| Standard Packaging: | box |
| Delivery Period: | 4 weeks |
| Payment Method: | T/T |
| Supply Capacity: | 20000pcs per month |
Model name: HNM02 5.8GHz Microwave motion sensor module HNM02
In some cases, customers want to upgrade their intelligent products, and don't want to use the standard / finished
sensor product, they can design and produce their own sensor controls or integrated their intelligent system by
themselves to fit better for their demands and bring more added values to their fixtures, at the same time save
cost deeply. This antenna module is smaller and stabilitier, lower cost for the customers.
Product Information:
Super compact size: 23.5*18.5mm, pin can be cusotmized
Low power consumption (Pulse mode): Average current: 1.2mA typ.
Pulse width (min.): 10~50μs (10kHz~2kHz) .
| 1 | Model name: HNM02 |
| 2 | 5.8GHz C-band microwave miniature transceiver, patch antenna, |
| 3 |
Antenna gain: 3 dBi. |
| 4 | 1Hz ~ 2KHz for receiver bandwidth |
| 5 | 6dBm EIRP for Output power |
| 6 | Beam aperture: 30°. |
| 7 | Pin: four pcs |
| 8 | Duty cycle:10% DC |
| 9 | IP20 & 5 years warranty |
PIN Description:
| PIN | Name | Description |
| 1 | VCC | 5 +/- 0.25V DC |
| 2 | GND | / |
| 3 | IF Output | / |
| 4 | NC | Fix PIN |
FAQ:
1. What is the delivery date:
Generally 1 week in stock for standard version, and 3-4 weeks without stock.
|
|
